Steel Frame 50m2 Modular House A++

Total Area: 50 m² Overall Dimensions: 8.00 m (length) × 6.24 m (width)

Structural System:

  • High‑strength steel frame construction
  • Engineered for long‑term durability, stability, and precision assembly

External Wall Build‑Up:

  • 160 mm PIR sandwich panel (premium thermal insulation)
  • Additional 100 mm mineral wool layer for the roof

Internal Wall Build‑Up:

  • 100 mm PIR insulated panels
  • Excellent thermal and acoustic separation between rooms

Roof Heights:

  • Height to eaves: 3.10 m
  • Height to ridge: 3.50 m
  • Spacious internal volume with comfortable ceiling height throughout
Category: Tag:

Modular House includes:

  • Premium aluminium triple‑glazed windows and doors
  • Air‑to‑air heating system and heat‑recovery ventilation (recuperation)
  • Full electrical installation – Hager electric
  • Water supply and drainage points prepared for the kitchen and bathroom
  • Structural frame: S355 steel construction
  • Exterior cladding: metal panels with wood‑effect finish
  • Kitchen with integrated appliances
  • Fully furnished bathroom: shower cabin, WC, sink, cupboards, heated towel rail
  • Bathroom floor heating
  • Complete interior finish
  • Laminate flooring throughout
  • Bathroom floor: vinyl covering
  • Infrared panel floor‑heating system
  • High‑quality stretch ceilings (Infiniline film)
  • Full LED lighting installation
  • Decorated internal walls
  • Wall structure: PIR 160mm + 100mm mineral wool
  • Each room has its own floor‑heating panel for individual temperature control.
  • The air‑conditioning system provides heating in winter and cooling in summer.

The home consists of two modules seamlessly connected together.
